Our homes are also becoming more automated as we move toward a digital world. In addition to that, having a motion sensor with lights in your house is a neat feature. Furthermore, you can do the installation yourself. This article will show you how to wire a motion sensor to multiple lights if you do not know how. Keep reading to find out everything there is to know about installing a motion detection system.
Precautions
Please wait a moment if you are doing this for the first time. When you have experience with wiring, connecting a motion sensor should be no problem for you. But if you’re not familiar with wiring, you could get hurt. In the event of an accident, electric wires can cause significant damage. Thus, if you have no experience with electrical work, you should ask an experienced friend for assistance. On the other hand, proceed if you know how these works are performed.
Nevertheless, you should take some precautions before getting started, including:
- The bulbs should be turned off. However, some bulbs have several sources of power. Make sure that there is no current by using a voltage tester.
- Hands should not be wet when working.
- Inspect the wires for leaks and make sure they’re in good shape.
Materials You Need
There are certain materials and tools needed for every work. Unless you prepare them before starting, the entire process will be much longer. Hence, before you begin wiring the motion sensor with lights, you should ensure that the following materials are available:
- A motion detector with a threaded interface.
- Some wire nuts to gauge the cables.
- Screwdriver.
- Wire strippers/Pliers.
- Voltage tester.
- Electric tape.
You can start working as soon as you have these tools ready.
How to Wire a Motion Sensor to Multiple Lights
We hope you have taken all the necessary precautions and prepared the tools. It is pretty simple to wire movement sensors into a single light. It becomes more complicated when there are multiple lights. Our detailed guide will walk you through each step. Please follow the instructions below to wire multiple lights with a motion sensor successfully:
Step 1: Prepare the Bulbs
Getting the bulbs ready for use is the first step. Fortunately, this is a relatively simple procedure. First, you will need to remove all of the bulbs from the fixtures. Once the bulbs have been removed, remove the fixtures. They need to be taken down because that is where you need to do the wiring.
Step 2: Get the Motion Tracker
Now that the lights are ready get the motion tracking device. Take it out of its box. A rubber gasket is also included with the tracker. To connect all cables, you need to feed them through the gasket. Ensure that the cables go through the knockout holes of the lightbox. Leave some room around the motion sensor to screw it in.
Step 3: Wiring
It’s now time for the most critical part, wiring. At the very least, you should know something about wires. If you don’t, you might find this step challenging. However, the motion tracker is equipped with three different types of wires: white, black, and red. All of these wires have unique features. There are also three wires on the light and house, one white, one black, and one ground wire. To install the light, follow the steps below carefully:
- Connect both the white wires of the fixture and the house to the white wires of the motion tracker simultaneously.
- Next, connect the black tracker cable with the house’s black cable.
- Once that is done, connect the red cable of the motion tracker with the black cable of the fixtures.
- Complete the wiring by connecting the ground wire.
- Wrap all the wires carefully with electrical tape after connecting them. However, keep in mind that this wiring step is essential to the whole sensor installation process.
You should follow the instructions carefully and be sure to avoid mistakes. This will save you from having to repeat everything.
Step 4: Check Everything is Right
At this point, you are almost finished. To prevent failure, you should verify everything once more. Examine the connections and tape. You should also check the power.
Step 5: Reinstall the Bulbs
Lastly, you need to reinstall the bulbs on the fixtures. And also, face the motion tracker in any direction you like. Check that the sensor is working properly afterward. Check if the sensitivity is acceptable. You should also check the time control system to ensure it is working properly. This was the five-step process of installing multiple lights with motion sensors at your home. Alternatively, if you do not feel comfortable with the process, a professional electrician will be able to assist you. They will make sure you don’t endanger yourself.
Conclusion
It is incredibly easy to wire multiple lights together with a motion sensor. This means that you shouldn’t have any issues doing it. However, electrical work is inherently dangerous. Therefore, read the article more than once if you need to. But do your best not to make mistakes.
